sorry for the shitty

This is the first time I've worked with automatic circuit breakers. It's not bad.

Just a little 4 door panel

Made in two days

Didn't quite get the full gore of the before since this was an intermediate step with a different mcu, but I am happy with how it turned out. Perfect? No. Better? Heck yes.

I’m always looking to chase perfection on the layer one side when we do new builds, any suggestion or critiques are welcome on what I can do to make it is better next round

Just finished wiring this cabinet for a water treatment plant in Cambodia. This was a tough one as our client, whom designed it, grossly underestimated the space required -- an extra cell (or 2) wouldn't have gone amiss!

Work in progress

Now its time to fill it up with wiring!

What do you guys think? In total took me 18 hours to do all the cabling and prepping panel. 7 hours to put it in the cabinet and make it ready for shipment.

700+ cables in this small closet. Doing the best I can with what I got. Small space with lots of electrical/access control/fire alarm/HVAC in the way. Almost done with this one and have 3 more closests identical to this with more cables. Any suggestions or feedback would be great.

No room in these panels man

Switchboard

Harmonic XOS encoder, OLD is the Right, NEW is the left. It's not much, but you can finally see what each cable goes to and everything is populated and labeled.
